78ft Monohull Classic Italian Yatch

Classification: CE

Class: A

Technical Data

LOA x Beam x Height (m): 23.77 x 6.1 x 8.26 Masthead light excluded

LOA x Beam x Height (m): 23.77 x 6.1 x 9.61 Masthead light included

Design draft (m): 1.24m

Fuel capacity (L): 5000L

Fresh water capacity (L): 700L

Black water capacity (L): 300L

Grey water capacity (L): 300L

Displacement (T): 65T

Cruising speed (knots): 14~15

Max speed (knots): 18~19

Propulsion System

Engines Option: VOLVO D13-1000x2 (VOLVO PENTA origin in SWEDEN)

Fuel: Bow thruster DC24 TT300

Bow thruster: DC24 TT300 (“Lewmar” origin in UK)

Stern Thruster: DC24 TT300 (“Lewmar” origin in UK)

Hydraulic steering system: Optimus EPS5000 (Seastar origin in USA)

Ni-Al-Bronze propellers:

Dripless shaft seals: 3.5"X5.5" (PYI / USA)

SS316 shaft:

Engine instrumentation, control devices & electronics devices at both helm positions: Supplied with Volvo engines

Trim tabs with anticorrosion protection: DC24V/TPA42*16” (“BENNETT” origin in USA)

Diagram View of All the Angles

No. Descriptions Notes
1. FRP molded hull with gel coat finish Exterior in gel coat finish (“DSM gel coat, origin in Holland”)
2. Vinylester resin hull surface layers against osmosis 901-TP
3. Multi-axial stitched fiberglass & unsaturated polyester reinforce hull construction
4. Hull bottom antifouling paint (blue water, origin in Singapore)
5. PVC cored sandwich construction
6. Watertight bulkhead structure 25mm PVC (Custom made, Origin in China)

No. Descriptions Notes
7. Stainless steel calibrated chain 100M/ Ø 12mm Origin in China
8. Electric anchor winch 24V/3000W “QUICK” origin in Italy
9. Stainless Steel Anchor 80KG (origin in China)
10. Windshield wipers DC24V x 2
11. Marine horn DC24V/ twin horns
12. Navigation lights DC24V
13. Safety rails SS316
14. Mooring system SS316 Cleats / Fairleads (custom, Origin in China)
15. Swim ladder w/ cover at swim platform 6 ladder stainless steel
16. Deck drain SS316 (Custom made, Origin in China)

No. Descriptions Notes
17. Wood Panel Pattern options available (colour & pattern to be confirmed)
18. Wall & window frames decoration Microfiber leather(colour & pattern to be confirmed)
19. Interior Sofa Laminate wood flooring(colour & pattern to be confirmed)
20. Toilet flooring Marble flooring
21. Aft cockpit, swim platform floor Teak flooring
22. Flybridge floor Teak flooring
23. Foredeck, side deck floor Teak flooring
24. Gate to main deck saloon Glass sliding door with stainless steel frame(Manual)
25. Main deck helm station Integral molded FRP w/ white gel coat
26. Main deck helm station (Custom made, Origin in China)
27. Fly bridge helm station Integral molded FRP w/ white gel coat
28. Fly bridge helm station (Custom made, Origin in China)
29. Fore deck escape hatch
30. Captain Seat (2*each helm station)
31. Aft cockpit Teak table
32. Fly bridge table Teak table
33. Galley cabinet Handmade wood panel cabinet & wall cupboard
34. Curtain (Custom made, manual, Origin in China)
35. Bathroom w/ separate shower compartment Alu frame with 8mm termpered glass
36. Front windscreen 5+5Thermal bending laminated glass (clear)
37. Front windscreen (“FUYAO” origin in China )
38. Side windows glass 6+6 Thermal bending laminated glass (grey)
39. Side windows glass (“FUYAO” origin in China )
40. Portholes LS-1020/LS-1000 (“MANSHIP” origin in Taiwan )
41. Hull side watertight window glass 8+8 Laminated tempered glass (grey)
42. Hull side watertight window glass (“FUYAO” origin in China )
43. Aft deck safety door
44. Deck wash faucet
45. Fly bridge counter Manufactured Stone

No. Descriptions Notes
46. Refrigerator 180-220L
47. Mini Bar WAECO
48. Oven
49. Induction cooker
50. Range hood
51. Dish Washer
52. Electric flash toilet DC24V (“TECMA” origin in Taiwan )
53. TV 40”-70” according to the layout
54. Sound system background sound system (Fusion origin in New Zealand)

No. Descriptions Notes
55. Generator AC220V/27KWx1 (“ONAN ” origin in USA )
56. Battery charger DC24V/100A /60A /40A (Victron origin in Holland)
57. Inverter 5kw (Victron origin in Holland)
58. Battery for port engine 200AHx2 origin in China
59. Battery for starboard engine 200AHx2 origin in China
60. Battery for generator 120AHx2 origin in China
61. Battery for household appliances 200AHx4 origin in China
62. Battery for anchor winch 200AHx2 origin in China
63. Battery for navigation system 120AHx2 origin in China
64. Shore power system & inlet AC220V/63Ax2 (Marinco origin in USA)
65. Rudder angle indicator DC24V
66. Engine room auto fire extinguisher system w/ alarm device at main helm station MA2-1250-227 (Fireboy origin in USA)
67. Fuel visual gauge/Fuel monitoring system TS1-V10 (“BEP” origin in USA )
68. Water heater 60L
69. Shower drain pump DC24V (Rulle origin in USA)
70. Fresh water pump DC24V (JABSCO origin in USA)
71. Auto bilge pumps at forward bilge, engine room & rudder bay DC24V (Rulle origin in USA)
72. Manual bilge pump 15010 (TMC origin in Taiwan)

No. Descriptions Notes
73. Marine Integrated Air Conditioning with cooling and heating system

100-120CK (GREE origin in China)

No. Descriptions Notes
74. Fly bridge helm radar color display 12″ (“Raymarine” origin in UK )
75.

Main deck helm radar color display

16″ (“Raymarine” origin in UK )

76.

Engine Display

Volvo 12”+16”

77.

Satellite antenna

(“Raymarine 45STV” origin in UK )

78.

High speed magnetic compass

79.

Main helm station VHF radio system

VHF/DC12V

No. Descriptions Notes
80.

As per CE regulation
