64ft Monohull Agile Italian Yatch

Classification: CE

Class: A

Technical Data

LOA x Beam x Height (m): 19.60x5x7.39 Masthead light not included

LOA x Beam x Height (m): 19.60x5x8.81 Masthead light included

Design draft (m): 1.03m

Fuel capacity (L): 3000L

Fresh water capacity (L): 600L

Black water capacity (L): 300L

Grey water capacity (L): 400L

Loaded displacement (T): 36T

Cruising speed (knots): 10~11

Max speed (knots): 14~15

Certification: CE

Propulsion System

Engines Option: VOLVO D13-800hpx2

Fuel: Diesel

Bow thruster: DC24V/CT165 Maxpower/ Origin in France

Stern thruster: DC24V/CT165 Maxpower / Origin in France

Hydraulic Steering System: PA Steering (Seastar/ USA)

Engine instrumentation, control devices & electronics devices at both helm positions:

Ni-Al-Bronze propellers: Custom made origin in China

Dripless shaft seals: 2.5"x4" PYI (USA)

AQAU Shaft:

Trim tabs with anti corrosion protection: DC24V (“BENNETT” origin in USA)

Diagram View of All the Angles

No. Descriptions Notes
1. FRP moulded hull with gel coat finish Exterior in white gel coat finish (“DSM” gel coat origin in Holland)
2. Marine resin hull surface layers against osmosis 901-TP
3. PVC cored sandwich construction
4. Multi-axial stitched fiberglass & unsaturated polyester reinforce hull construction
5. PVC watertight bulkhead structure 25mm
6. Hull bottom antifouling paint Blue water (origin in Singapore)
7. anti-corrosion paint “Prop Speed” Prop Speed origin in NZ

No. Descriptions Notes
8. Electric anchor winch DC24V/RG5-2324DY/X “QUICK /Origin in Italy”
9. Plough anchor 50KG origin in China
10. Stainless Steel anchor chain 75M/ Ø 12mm
11. Windshield wipers DC24V Origin China
12. Marine horn DC24V/ twin horns
13. Full set of navigation lights DC24V (AQUA)
14. Safety rails SS316
15. Mooring system SS316 Cleats / Fairleads
16. Swimming ladder Movable /hung at platform
17. Deck drain SS316

No. Descriptions Notes
18. Wood Veneers Matt Finish, Pattern option available
19. Leather Linen / microfiber leather wall upholstery
20. Interior Sofa Integral custom made sofa / microfiber leather
21. Exterior Sofa FRP base with waterproof fabric
22. Interior floor Composite Wood flooring
23. Aft deck floor and swimming platform floor Teak floor
24. Side deck, fore deck and flybridge deck floor Teak floor
25. Sliding door to main deck saloon Stainless steel framed sliding door with lock(manual)
25. Main deck helm station Integral leather upholstery with panel
25. Fly bridge helm station Integral molded FRP w/ white gel coat
25. Aft cockpit and fly bridge table Teak
25. Main deck helm seats Wood sofa base with cushion
25. Fly bridge helm seats FRP sofa base with waterproof sofa cushion
25. Fore deck escape hatch
25. Bar / head countertop Artificial stone top
25. Side access Side access at the aft deck

No. Descriptions Notes
26. Refrigerator 180L-200L (Media / origin in China)
27. Induction cooker Simens / origin in China
28. Range Hood AScoli / Italy
29. Oven Simens / Origin in China
30. Dish Washer AEG / Origin in China
31. Ice Maker
32. TV 40”-60″ Origin in China
33. Electric flash toilet DC24V Jabsco/USA
34. Sound system background sounding (Fusion origin in NZ)
35. Water maker Rainman 230 (Origin in Australia)

No. Descriptions Notes
36. Generator AC220V/15KW CAT (Origin in USA)
37. Battery for engines 200AHx4 origin in China
38. Battery for generator 120AHx2 origin in China
39. Battery for household appliances 200AHx4 origin in China
40. Battery for navigation system 200AHx1 origin in China
41. Battery for Anchor winch 200AHx2 origin in China
42. Battery charger DC24V/100A/60A/40A (Victron / Holland)
43. Inverter 3kw Victron / Holland
45. Shore power system AC220V/63A*1 MARINCO (USA)
46. Auto fire extinguisher at engine room Ma2-700-227 (Fireboy/ USA)
47. Rudder indicator DC24V (KUS / USA)
48. Water heater 40L
49. Shower drain pump DC24V RULE (USA)
50. Fresh water pump with filter DC24V JABSCO (USA)
51. Auto bilge pump DC24V RULE (USA)
52. Manual bilge pump 15010 TMC (TAIWAN)

No. Descriptions Notes
53. Fly bridge helm radar display Color display 9″ Garmin
54. Main deck helm radar display Color display 12” Garmin
55. Antenna 45STV Intellian origin in Korea
56. Autopilot Garmin
57. anemoclinograph Garmin gWind
58. Stern seraching light Golight / USA
59. Main helm station VHF radio system VHF/DC12V Garmin
60. High speed magnetic compass / AIS

No. Descriptions Notes
61. Marine air conditioning set , with cooling and heating for all rooms 84CK

No. Descriptions Notes
62. Fire and life saving equipment must comply with USCG
63. Fireboy or Seafire for fire alarm, DELTA for air brake
